Performance characteristic:
steel welded construction, vibration to eliminate stress, with high strength, good rigidity of.
hydraulic transmission, stable and reliable .
mechanical block, synchronous torque, and high precision .
back-gauge distance, slider stroke electric adjustment, manual fine tuning, digital display.
module equipped with deflection compensation mechanism.

规格型号	公称压力	工作台长度	立柱间距离	喉口深度	滑块行程	行程次数 (次/分)	主电机功率	机床外形尺寸 (长×宽×高)
	KN	mm	mm	mm	mm	min-1	KW	mm (L×W×H)
40/2000	400	2000	1650	200	100	≥11	3	2100×1580×1860
50/3200	500	3200	2600	200	100	≥11	3	3300×1650×1980
63/2500	630	2500	2050	250	100	≥10	5.5	2600×1755×2220
63/3200	630	3200	2600	250	100	≥10	5.5	3300×1755×2250
80/3200	800	3200	2600	250	100	≥8	7.5	3300×1760×2250
80/4000	800	4000	3200	250	100	≥8	7.5	4100×1760×2450
100/3200	1000	3200	2600	320	120	≥8	7.5	3300×1800×2445
100/4000	1000	4000	3200	320	120	≥8	7.5	4100×1800×2575
125/3200	1250	3200	2600	320	120	≥8	7.5	3300×1800×2445
125/4000	1250	4000	3200	320	120	≥8	7.5	4100×1800×2575
160/3200	1600	3200	2600	320	200	≥8	11	3300×2005×2760
200/3200	2000	3200	2600	320	200	≥7	15	3300×2175×2650
200/4000	2000	4000	3200	320	200	≥7	15	4100×2175×3070
250/6000	2500	6000	4800	400	250	≥3	18.5	6100×2370×4515
300/6000	3000	6000	4800	400	250	≥3	22	6100×2630×4850
400/6000	4000	6000	4800	400	300	≥2.5	30	6100×2772×5060
500/6000	5000	6000	4800	400	320	≥2.5	37	6100×2800×5300
600/6000	6000	6000	4800	400	320	≥2.5	37	6100×3000×5800
